UltraVac+

Vacuum & Drying Chamber

Designed to give dispensers and technicians a functional tool for repairing, restoring and maintaining hearing aids.

  • The UltraVac+ is easy to use – which makes it ideal for those who may just be getting started but powerful enough for the demands of the most experienced technician.

  • Functions of your UltraVac+

    • The Drying Chamber – Displaces moisture trapped within the hearing instruments. You can place two ITEs, or one BTE with an earmold, into the chamber at one time.
    • The Vacuum Wand – Used to extract ear wax and debris from the receiver tubes, microphone tubes, vents and battery compartments of the hearing instruments.
    • The Pressure Function – Used to clear obstructed Vacuum Wand Tips and to blow debris from the receiver tubes, microphone tubes, vents and battery compartments of the hearing instruments.

    The Vacuum & Pressure Wands work simultaneously. The Wands and the Drying Chamber cannot be used simultaneously. By turning on one of these functions, the other will automatically be turned off.

  • UltraVac+ features:

    • 4 minute Drying Chamber cycle with auto shut off
    • Display panel indicates the vacuum level of the Drying Chamber and time remaining during use
    • Separate Pressure and Vacuum Wands work simultaneously
    • In-line Vacuum Hose filter – minimize debris in the system
    • Easy to use and easy to keep clean
  • Changing the Drying Chamber Filter

  • Changing the Vacuum Wand Filter

Technical Specs

  • Power Requirements:
    100 – 240 V, 50/60 Hz

    Power Consumption: <100 Watts

    Fuse: 2.5A @ 100-240V

  • Operating Temperature:
    32° to 120° F • 0° To 50° C

    Weight: Approx 11 lbs • Approx 5 kg

    Dimensions:
    Approx 11.25” x 12” x 6.25” (L x W x H)
    Approx 29 cm x 31 cm x 16 cm (L x W x H)

  • Debris Filter: I-63S

    Vacuum Tips: #14, #15, 2-#18 and 2-#20 Gauge With Safety Lock Attachment

    Drying Chamber Cycle Time: 4 Minutes With Auto Shut-off

  • Vacuum Wand: Continuous Use

    Pressure Wand: Continuous Use

    Standard Accessories: Drying Chamber Cup With Filter, Vacuum Wand With Filter, Pressure Wand, O-Ring, 6 Vacuum Wand Tips, Cleaning Tool Kit, Instruction Manual
