AVANT AIR+

PC-Based Screening Audiometer

The MedRx AVANT AIR+ has air threshold capabilities allowing additional versatility. The small footprint makes it an ideal air audiometer for traveling. Use this product for community screenings where air thresholds are needed.

  • Air Threshold Testing
  • Automatic Air Audiometry Testing 125 Hz – 8 kHz
  • Small Footprint – Approx. 12 cm x12 cm x 3 cm (L x W x H) Approx. 5” x 5” x 1.25” (L x W x H)
  • PC Based via USB Connection
  • NOAH™, TIMS®, Blueprint OMS and Sycle Compatible
  • air-1
  • air-2
  • air-3
  • air-4

Technical Specs

  • Standards:
    Screening Audiometer as per ANSI S3.6-2018, IEC 60645-1:2012, Type 4; Tone Audiometry.

    Outputs:
    DD65v2 Headphones

    Frequency Range:
    Air: 125 Hz – 8 kHz

  • Max Output:
    Air Conduction: 100 dB HL For Mid-Range Frequencies

    Attenuation:
    1 dB Step Or 5 dB Step, User Selectable

    Optional Accessories:
    DD450 Headphones, DD45 Headphones & Insert Earphones

  • Compatible with:
    NOAH™, TIMS®, Blueprint OMS and Sycle

    Power Requirements: USB-powered

    Dimensions:
    Approx. 12 cm x 12 cm x 3 cm (L x W x H) Approx. 5″ x 5″ x 1.25″ (L x W x H)

    Weight: < 500 g  < 1 lb

  • Standard Accessories:
    DD65v2 Headphones, Patient Response Switch, Talkback Microphone, Operator Mic / Monitor Headset, Software & Manuals, Carrying Case
